ALP2 Gear Pumps Marzocchi
ALP2 Gear Pumps Marzocchi Aluminum
|
TYPE |
Displacement |
FLOW at |
MAX PRESSURE |
MAX SPEED |
||
|
P1 |
P2 |
P3 |
||||
|
|
cm³/rev |
litri/min |
bar |
bar |
bar |
rpm |
|
ALP2-D(S)-6 |
4.5 |
6.4 |
250 |
270 |
290 |
4000 |
|
ALP2-D(S)-9 |
6.4 |
9.1 |
250 |
270 |
290 |
4000 |
|
ALP2-D(S)-10 |
7 |
10 |
250 |
270 |
290 |
4000 |
|
ALP2-D(S)-12 |
8.3 |
11.8 |
250 |
270 |
290 |
4000 |
|
ALP2-D(S)-13 |
9.6 |
13.7 |
250 |
270 |
290 |
4000 |
|
ALP2-D(S)-16 |
11.5 |
16.4 |
230 |
250 |
270 |
4000 |
|
ALP2-D(S)-20 |
14.1 |
20.1 |
230 |
250 |
270 |
3200 |
|
ALP2-D(S)-22 |
16 |
22.8 |
210 |
225 |
240 |
2800 |
|
ALP2-D(S)-25 |
17.9 |
25.5 |
210 |
225 |
240 |
2500 |
|
ALP2-D(S)-30 |
21.1 |
30.1 |
180 |
195 |
210 |
2200 |
|
ALP2-D(S)-34 |
23.7 |
33.7 |
180 |
195 |
210 |
2000 |
|
ALP2-D(S)-37 |
25.5 |
36.4 |
170 |
185 |
200 |
1800 |
|
ALP2-D(S)-40 |
28.2 |
40.1 |
170 |
185 |
200 |
1800 |
|
ALP2-D(S)-50 |
35.2 |
50.2 |
140 |
155 |
170 |
1800 |
ALP hydraulic gear pumps with external gearing are used for pressure supply of oil medium to the hydraulic system, or only for pumping and filtering oil. The hydraulic gear pump can be in various sizes with the required oil flow of 3-30 ccm / rev, according to the customer's wishes. These hydraulic pumps with external gearing work with a continuous pressure of up to 270 bar.
| ALP1 TYPE | ALP2 TYPE | ALP3 TYPE |
| ALP1-D(S)-2 | ALP2-D(S)-6 | ALP3-D(S)-33 |
| ALP1-D(S)-3 | ALP2-D(S)-9 | ALP3-D(S)-40 |
| ALP1-D(S)-4 | ALP2-D(S)-10 | ALP3-D(S)-50 |
| ALP1-D(S)-5 | ALP2-D(S)-12 | ALP3-D(S)-60 |
| ALP1-D(S)-6 | ALP2-D(S)-13 | ALP3-D(S)-66 |
| ALP1-D(S)-7 | ALP2-D(S)-16 | ALP3-D(S)-80 |
| ALP1-D(S)-9 | ALP2-D(S)-20 | ALP3-D(S)-94 |
| ALP1-D(S)-11 | ALP2-D(S)-22 | ALP3-D(S)-110 |
| ALP1-D(S)-13 | ALP2-D(S)-25 | ALP3-D(S)-120 |
| ALP1-D(S)-16 | ALP2-D(S)-30 | ALP3-D(S)-135 |
| ALP1-D(S)-20 | ALP2-D(S)-34 | |
| ALP2-D(S)-37 | ||
| ALP2-D(S)-40 | ||
| ALP2-D(S)-50 |
High strength aluminum alloy material is applied, with light weight and easy installation
Axial clearance automatic compensation mechanism, radial hydraulic balance, maintaining high volumetric efficiency of the oil pump
CBW Hydraulic Gear Pump adopts self-lubricating bearings to improve the pump's load-bearing capacity
The connection forms of the inlet and outlet ports include threads, flanges, etc. for selection
The input shaft connection form can be selected from flat keys, rectangular splines, flat keys, semicircle keys, involute splines, SAE splines can be customized
