GHP3 Hydraulic Marzocchi Gear Pump

Short Description:

Group

GHP3

Size 30 33 40 50 60 66 80 94 110 120 135
Speed (rpm)

2000

1500 1000

We need more models of Alp gear pumps, please contact us for quotes and discounts.


Product Detail

Customer Feedback

Product Tags

Why choose us

POOCCA Hydraulic,is a professional manufacturer of Hydraulic gear pumps,which is integrated with R&D
1.Very competitive price.

2.Product Low-noise, high efficiency, high compatibility, long life.

3. Small size, high power density.

4.Excellent oil absorption properties.

GHP3 Pumps Parameter

GHP3 Hydraulic Marzocchi Gear Pump

Type Displacement Flow at 1500 rev/min Maximum Pressure Maximum Speed Dimensions
P1 P2 P3 L M d D h H
GHP3-D-30 20 29 280 295 310 3500 64 127 27 19 56 56
GHP3-D-33 22 31 280 295 310 3500 64.5 128 27 19 56 56
GHP3-D-40 26 37 280 295 310 3000 66 131 27 19 56 56
GHP3-D-50 33 48 270 285 300 3000 68.5 136 27 19 56 56
GHP3-D-60 39 56 260 275 290 3000 70.5 140 27 19 56 56
GHP3-D-66 44 62 250 265 280 2800 72 143 27 27 51 51
GHP3-D-80 52 74 230 245 260 2400 75 149 27 27 56 56
GHP3-D-94 61 87 210 225 240 2800 78 155 33 27 62 51
GHP3-D-110 71 101 200 215 230 2500 81.5 162 33 27 62 51
GHP3-D-120 78 112 180 195 210 2300 84 167 33 27 62 51
GHP3-D-135 87 124 160 175 190 2000 87 173 33 27 62 51

Dimension Drawing

Feature

Marzocchi GHP3:

  1. Displacement: The GHP3 series includes pumps with larger displacements, typically ranging from 53.3 cc/rev to 89.3 cc/rev, making them suitable for high-flow hydraulic systems.
  2. Maximum Pressure: GHP3 pumps are designed to handle even higher maximum pressures, often up to 350 bar (5,075 psi).
  3. Speed Range: These pumps are suitable for hydraulic systems operating within the range of 800 to 3,000 RPM.
  4. Mounting Type: GHP3 pumps offer various mounting options for flexibility in installation.



poocca hydraulic pump (6)

Our Services

poocca hydraulic pump (3)

Production Flow Chart

- Maximum Operating Pressure o6

Praise

poocca hydraulic pump manufacturer (9)
- Maximum Operating Pressure o1

FAQ

Q: Are you trading company or manufacturer?
A: We are manufacturer.
Q: How long is the Warranty?
A: One-year warranty.
Q: What is your payment terms?
A: 100%  in advance, long-term dealer 30% in advance, 70% before shipping.
Q: How about the delivery time?
A: Conventional products take 5-8 days, and unconventional products depend on the model and quantity

More Models

GHP1 TYPE GHP2 TYPE GHP3 TYPE
GHP1-D-2 GHP2-D-6 GHP3-D-30
GHP1-D-3 GHP2-D-9 GHP3-D-33
GHP1-D-4 GHP2-D-10 GHP3-D-40
GHP1-D-5 GHP2-D-12 GHP3-D-50
GHP1-D-6 GHP2-D-13 GHP3-D-60
GHP1-D-7 GHP2-D-16 GHP3-D-66
GHP1-D-9 GHP2-D-20 GHP3-D-80
GHP1-D-11 GHP2-D-22 GHP3-D-94
GHP1-D-13 GHP2-D-25 GHP3-D-110
GHP1-D-16 GHP2-D-30 GHP3-D-120
GHP1-D-20 GHP2-D-34 GHP3-D-135
GHP1A-D-2 GHP2-D-37 GHP3-D-30
GHP1A-D-3 GHP2-D-40 GHP3-D-33
GHP1A-D-4 GHP2-D-50 GHP3-D-40
GHP1A-D-5 GHP2A-D-6 GHP3-D-50
GHP1A-D-6 GHP2A-D-9 GHP3-D-60
GHP1A-D-7 GHP2A-D-10 GHP3-D-66
GHP1A-D-9 GHP2A-D-12 GHP3-D-80
GHP1A-D-11 GHP2A-D-13 GHP3-D-94
GHP1A-D-13 GHP2A-D-16 GHP3-D-110
GHP1A-D-16 GHP2A-D-20 GHP3-D-120
GHP1A-D-20 GHP2A-D-22 GHP3-D-135
GHP2A-D-25
GHP2A-D-30
GHP2A-D-34
GHP2A-D-37
GHP2A-D-40
GHP2A-D-50
